Paper, plastic, or standby power
View the full story, including all images and figures, in our monthly digital edition.
In 2005, Hurricane Katrina damaged the Gulf Coast of the United States, particularly New Orleans. In response to the natural disaster, Winn-Dixie Stores Inc. enacted a program that allowed them to rebuild damaged grocery stores in the event that a hurricane or other natural disaster caused them to close.
In October 2007, the Winn-Dixie store in New Orleans East marked a significant milestone by hosting the remote NASDAQ opening. The event marked the first NASDAQ opening from a grocery store and the first ever in Louisiana.
The 50,709 sq ft facility was the first full-service grocery store to return to the community after the hurricane. Winn-Dixie chose to install a 600 kW diesel generator from Cummins Power Generation Inc. The weatherproof generator provides electricity to the entire store in the event of a power outage. Fully compliant with NFPA 110 for Level 1 systems, the generator provides the Winn-Dixie store with a graphical data display. The display allows the operator to view all engine and alternator data; perform operator adjustments for speed, voltage, and time delays; view fault history; and set up and adjust the generator set.
The standby generator features a PowerCommand iWatch wireless monitoring system that links the generator set with cellular and satellite networks. Users access operational data using the Internet or receive e-mails or text messages about alarm condition updates. The system uses a Modbus or hard-wired interface to communicate with a Web server. The standby generator, equipped with automatic transfer switches and a 3,600-gal, sub-base fuel tank, sits atop an 8-ft-high, flood-protected platform.
According to Shawn Sloan, director of energy for Winn-Dixie, the complete reconstruction of the New Orleans East store is part of a multi-phase effort in Alabama, Florida, Louisiana, and Mississippi to upgrade 500 stores within the next four years.
“When natural disasters strike, a full powered retail grocery location plays a critical role in the devastated communities. These standby generators will enable our stores to remain fully operational—providing refrigeration, lighting, and business services—in the event of a natural disaster or power outage,” Sloan said.
Cummins worked with its distributor, Cummins Power South LLC, as the primary equipment and service supplier. Winn-Dixie chose Preservation Power LLC to manage the project. The two companies collaborated to meet the aggressive schedule for the first two phases of the project, which include solving a number of store energy load management issues.
Preservation Power and its subcontractor, Chain Electric, expedited the permitting and commissioning process. Cummins compressed the delivery schedule on the 600-kW diesel unit, both of which set a record from order placement to commissioning and operation.
Information provided by Cummins Power Generation .
AT A GLANCE
Shortly before Hurricane Katrina hit New Orleans, Winn-Dixie Stores enacted a program that rebuilds damaged grocery stores in the event of a natural disaster. Winn-Dixie selected Cummins Power Generation to help them with the rebuilding process after the hurricane. In October 2007, the Winn-Dixie store in New Orleans East reopened and became the first full-service grocery store to return to the community.
Cummins Power Generation provided a 600 kW diesel generator to provide electricity to the entire store in the event of a power outage. Fully compliant with NFPA 110 for Level 1 systems, the generator provides the Winn-Dixie store with a graphical data display. The display allows the operator to view all engine and alternator data; perform operator adjustments for speed, voltage, and time delays; view fault history; and set up and adjust the generator set.
The standby generator features a PowerCommand iWatch wireless monitoring system that links the generator set with cellular and satellite networks. Winn-Dixie users can access operational data using the Internet or receive e-mails or text messages about alarm condition updates. The standby generator, equipped with automatic transfer switches and a 3,600-gal, sub-base fuel tank, sits atop an 8-ft-high, flood-protected platform.
